Descrizione
| Component | Tweeter |
| Size mm (in.) | 29 (1.14) |
| Power Handling – Peak W | 120 |
| Power Handling – Peak Note | (Hi-Pass filtered @ 2,5kHz – 12 dB Oct.) |
| Impedance Ohm | 4 |
| Voice Coil Ø | 25 (1) |
| Frequency Response Hz | 1.4k ÷ 22.5k |
| Magnet size D x d x h mm (in.) | 24.5 x 6 x 3.5 (0.96 x 0.24 x 0.14) |
| Weight of one speaker kg (lb.) | 0.07 (0.14) |
| Magnet | Neodymium |
| Dome | Tetolon |
| D mm | 29 |
| Re Ohm | 3,9 |
| Fs Hz | 1200 |
| Le mH | 0,02 |
| Vas I | – |
| Mms g | 0,17 |
| Cms mm/N | 0,1 |
| BL T*m | 1,6 |
| Qts | 0,55 |
| Qes | 1,98 |
| Qms | 0,57 |
| Spl dB | 91 |
Specifiche fisiche
| A | 44 mm | 1.73 in. |
| B | 41 mm | 1.61 in. |
| C | 27 mm | 1.06 in. |
| D | 17 mm | 0.67 in. |
Risposta in frequenza
